GIGABYTE Z890 AORUS ELITE DUO X Motherboard, Intel Z890, LGA1851, DDR5 up to 10266+MT/s OC, PCIe 5.0, Wi-Fi 7, USB4, ATX

عن المنتج

.pdesc-wrap{background:#1a1a1a;border-radius:12px;border:1px solid #2a2a2a;padding:24px;font-family:inherit;font-size:14px;line-height:1.75;box-sizing:border-box;width:100%;max-width:100%} .pdesc-intro{font-size:14px;color:#b0b6bf;line-height:1.85;margin:0 0 20px;word-break:break-word} .pdesc-intro strong{color:#6b9fff;font-weight:500} .pdesc-label{font-size:11px;font-weight:500;letter-spacing:0.09em;text-transform:uppercase;color:#4a5568;margin-bottom:10px} .product-specs-table{width:100%;border-collapse:collapse;margin-top:8px;table-layout:fixed} .product-specs-table tr{border-bottom:1px solid #2a2a2a} .product-specs-table td{padding:10px 12px;font-size:13px;line-height:1.6;vertical-align:top;border:none;word-break:break-word} .product-specs-table td:first-child{color:#6b9fff;font-weight:500;width:38%;letter-spacing:0.02em} .product-specs-table td:last-child{color:#d1d5db;font-weight:400} @media(max-width:480px){ .pdesc-wrap{padding:16px;border-radius:8px} .pdesc-intro{font-size:13px} .product-specs-table td{display:block;width:100%;padding:6px 8px} .product-specs-table tr{display:block;padding:8px 0;border-bottom:1px solid #2a2a2a} .product-specs-table td:first-child{width:100%;padding-bottom:2px;font-size:11px;letter-spacing:0.06em} .product-specs-table td:last-child{padding-top:0;font-size:13px} } GIGABYTE Z890 AORUS ELITE DUO X Motherboard is a motherboard featuring an Intel® Z890 Express Chipset, an LGA1851 socket supporting Intel® Core™ Ultra Processors, DDR5 memory support up to 10266+MT/s (OC), PCIe 5.0 x16, and Intel® Wi-Fi 7 BE200NGW, making it a motherboard available in Egypt through Compumarts. Key specs CHIPSET Intel® Z890 Express Chipset SOCKET LGA1851 socket: Support for Intel® Core™ Ultra Processors MEMORY Support up to 10266+MT/s (OC) WIRELESS Intel® Wi-Fi 7 BE200NGW CONNECTIVITY Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) FORM FACTOR ATX Form Factor; 30.5cm x 24.4cm GIGABYTE Z890 AORUS ELITE DUO X Motherboard is a motherboard featuring an Intel® Z890 Express Chipset, an LGA1851 socket supporting Intel® Core™ Ultra Processors, DDR5 memory support up to 10266+MT/s (OC), PCIe 5.0 x16, and Intel® Wi-Fi 7 BE200NGW, making it a motherboard available in Egypt through Compumarts. Key specs CHIPSET Intel® Z890 Express Chipset SOCKET LGA1851 socket: Support for Intel® Core™ Ultra Processors MEMORY Support up to 10266+MT/s (OC) WIRELESS Intel® Wi-Fi 7 BE200NGW CONNECTIVITY Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) FORM FACTOR ATX Form Factor; 30.5cm x 24.4cm

تفاصيل إضافية

GIGABYTE Z890 AORUS ELITE DUO X Motherboard is a motherboard featuring an Intel® Z890 Express Chipset, an LGA1851 socket supporting Intel® Core™ Ultra Processors, DDR5 memory support up to 10266+MT/s (OC), PCIe 5.0 x16, and Intel® Wi-Fi 7 BE200NGW, making it a motherboard available in Egypt through Compumarts. Key specs CHIPSET Intel® Z890 Express Chipset SOCKET LGA1851 socket: Support for Intel® Core™ Ultra Processors MEMORY Support up to 10266+MT/s (OC) WIRELESS Intel® Wi-Fi 7 BE200NGW CONNECTIVITY Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) FORM FACTOR ATX Form Factor; 30.5cm x 24.4cm

المواصفات الفنية

ARGB Headers

3 x Addressable RGB Gen2 LED strip headers

Audio Codec

Realtek® ALC1220 CODEC

Audio Support

High Definition Audio 2/4/5.1/7.1-channel

BIOS

1 x 512 Mbit flash

BIOS Standards

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

BIOS Type

AMI UEFI BIOS

Back Panel

Reset button, Power button, Clear CMOS button, Q-Flash Plus button, 2 x USB 3.2 Gen 2 Type-A, 1 x DisplayPort, 4 x USB 2.0/1.1, 3 x USB 3.2 Gen 1, 1 x USB4 Type-C, 2 x antenna connectors, 1 x RJ-45, 1 x Optical S/PDIF Out, 2 x audio jacks

Bluetooth

Bluetooth 5.4

Bundled Software

Norton® Internet Security (OEM version)

CHIPSET

Intel® Z890 Express Chipset

CONNECTIVITY

Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)

CPU Fan Header

1

CPU M.2 Slot 1

Socket 3, M key, 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD

CPU M.2 Slot 2

Socket 3, M key, 22110/2280 PCIe 4.0 x4/x2 SSD

CPU PCIe Slot

1 x PCI Express x16 slot, PCIe 5.0 x16

CPU Power

2 x 8-pin ATX 12V power connectors

CPU Pump Header

1

CPU Support

LGA1851 socket: Support for Intel® Core™ Ultra Processors

CQDIMM Support

Support up to 8000 MT/s (OC)

Category

Specification Details

Chipset

Intel® Z890 Express Chipset

Chipset M.2 SATA Slot

Socket 3, M key, 22110/2280 SATA and PCIe 4.0 x4/x2 SSD

Chipset M.2 Slots

2 x Socket 3, M key, 22110/2280 PCIe 4.0 x4/x2 SSD

Chipset PCIe Slots

2 x PCI Express x16 slots, PCIe 4.0 x4

Clear CMOS Jumper

1

Dimensions

30.5cm x 24.4cm

DisplayPort

1 x DisplayPort

DisplayPort Maximum Resolution

4096x2304@60 Hz

DisplayPort Version

DisplayPort 2.1

ECC Memory Support

Support ECC (operate in non-ECC mode), Non-ECC, Quad-Rank Un-buffered DIMM memory modules

FORM FACTOR

ATX Form Factor; 30.5cm x 24.4cm

Form Factor

ATX

Front Audio Header

1

Front Panel Header

1

HDCP

HDCP 2.3

Hardware Monitoring

Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control

I/O Controller

iTE® I/O Controller Chip

Integrated Graphics

Integrated Graphics Processor-Intel® HD Graphics support

Internal USB-C

1 x USB Type-C® header with USB 3.2 Gen 2 support

L3 Cache

L3 cache varies with CPU

LAN

Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)

M.2 Connectors

5 x M.2 Socket 3 connectors

MEMORY

Support up to 10266+MT/s (OC)

Main Power

1 x 24-pin ATX main power connector

Maximum Memory

256 GB

Memory Architecture

Dual Channel

Memory Slots

2 x DDR5 DIMM slots

Memory Support

Support up to 10266+MT/s (OC)

Operating System

Windows 11 64-bit

Product Name

GIGABYTE Z890 AORUS ELITE DUO X

Product Type

Motherboard

RAID Support

RAID 0, RAID 1, RAID 5, RAID 10 for NVMe SSD and SATA storage devices

RGB Header

1 x RGB LED strip header

Rear USB 3.2 Gen2

2 x USB 3.2 Gen 2 Type-A ports

Rear USB4

1 x USB4® USB Type-C® port

Reset Jumper

1

S/PDIF Support

Support for S/PDIF Out

SATA

4 x SATA 6Gb/s connectors

SOCKET

LGA1851 socket: Support for Intel® Core™ Ultra Processors

System Fan Headers

3

System Pump Header

1

TPM Header

1

Thunderbolt Add-in Connectors

2

USB 2.0

8 x USB 2.0/1.1 ports

USB 2.0 Headers

2

USB 3.2 Gen1

5 x USB 3.2 Gen 1 ports

USB 3.2 Gen1 Header

1

USB Type-C Header

1

USB4 Maximum Resolution

4096x2304@144 Hz

USB4 Video Output

1 x USB4® USB Type-C® port supporting USB4 and DisplayPort video outputs

Unique Features

GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup

WIRELESS

Intel® Wi-Fi 7 BE200NGW

Wi-Fi Bands

2.4/5/6 GHz

Wi-Fi Standards

802.11a, b, g, n, ac, ax, be

Wireless

Intel® Wi-Fi 7 BE200NGW

Wireless Standard

11be 320MHz

XMP Support

Supports Intel® Extreme Memory Profile (XMP) memory module
